Our Watering can blow molding machine is a professional equipment for producing high-quality plastic watering cans, compatible with HDPE, PE, PP materials to make 0.1L-30L products.
Our Watering can blow molding machine is a professional equipment for producing high-quality plastic watering cans, compatible with HDPE, PE, PP materials to make 0.1L-30L products. It integrates PLC intelligent control, high-precision mold clamping and efficient extrusion systems, ensuring stable molding, uniform wall thickness and fast cycle speed. With low energy consumption, easy operation and convenient maintenance, it realizes automatic production from raw material to finished product, greatly improving production efficiency and reducing costs for your watering can manufacturing business.
1. Double-Head 1–2L Watering Can Blow Molding Machine
● Dual-head synchronous production, output doubles vs single-head models
● High-precision mold alignment, product consistency rate ≥99%
● Online deflashing, less manual work, higher efficiency
2. Triple-Head 500–1000ML Mini Watering Can Blow Molding Machine
● Three-cavity molding, 3000–4000 pcs/h high output
● Uniform plasticization, finished products with smooth surface
● Energy-saving design, 15% lower heating energy consumption
3. Double-Head Double-Layer Watering Can Blow Molding Machine
● Dual-layer co-extrusion, anti-UV & anti-corrosion performance
● Independent temperature control, supports multi-color production
● 260KN high clamping force, adapts to special-shaped molds
4. Triple-Head High-Speed Watering Can Blow Molding Machine
● 6-second short dry cycle, ultra-fast production rhythm
● Servo motor drive, scrap rate below 1%
● Compact structure, 30% less floor space
5. Double-Head Customizable Watering Can Blow Molding Machine
● Mold size customizable, fits diverse watering can specs
● Supports full-auto production line integration
● Wear-resistant screw & die head, long service life
|
Model NO. |
YSD-PY20L |
Raw Material |
HDPE/PP/LDPE |
|
Making Method of Parison |
Extrusion-Blow Molding |
Automation |
Semi Automatic |
|
Computerized |
Computerized |
Certification |
CE, ISO9001:2008, Ysd |
|
After-sales Service |
24 Hours |
Machine Type |
High Speed Plastic Bottle Making Machine |
|
Control Mode |
PLC |
Motor Power |
11kw |
|
Total power |
17.5kw |
Blow Moulding Type |
Extrusion Blow Moulding |
|
Auto Deflashing |
Available |
Output(Dry Cycle) |
180PC/Hr; |
|
Die Head Option |
Single, Double, Tri-Head, Tetra-Head |
Production Usage |
Bottle, Toy, etc |
|
Max Container Capacity |
20L |
Transport Package |
Wooden Case |
|
Specification |
2800*1800*2000mm |
Trademark |
YSD |
|
Origin |
China |
Production Capacity |
500 |
|
Screwed diameter |
80mm |
|
Screwed diameter ratio |
1:25L/D |
|
HDPE Max Output |
40kg/h |
|
Material cutting method |
Hot knife |
|
Max mold size(L×W×H) |
220×300×380mm |
|
Blowing pressure |
0.4-0.6Mpa |
|
gas consumption |
0.5m3/min |
|
Power of mechanical and electrical extruder |
11KW |
|
Heating power of extruder |
10KW |
|
Total power |
23KW |
|
Dimension mm(L X W X H) |
2800*1800*2000mm |
|
Weight |
2.0T |
|
Control type |
PLC PC Control |
|
Suitable material |
PE/PP |
“ Customized services are superb! The manufacturer optimized the mold design based on our bottle type requirements, directly enhancing the competitiveness of the product by one level. “
“ This machine fully complies with international standards and has helped us win multiple major overseas clients. “
“ Blow molding machines have a high degree of automation, simple and easy to operate, significantly reducing labor costs, and production efficiency is higher than expected “
“ The equipment has high molding accuracy, and the blow molded products have uniform wall thickness and smooth appearance, fully meeting our quality requirements for mass production “
“ Super stable operation, continuous operation without faults for several months, low maintenance costs, and cost-effective long-term use “
“ In response to our special product requirements, the manufacturer provides customized blow molding solutions that are adaptable and practical “
We offer a wide range of blow molding machines, extrusion blow molding machines, plastic blow molding machines and bottle blow making machines.
Equipped with a professional technical team to provide one-on-one services throughout the entire chain of "requirement communication - solution design - equipment research and development - installation and debugging - after-sales maintenance"
