JerryCan
Our Semi-Automatic Oil Pot Blow Molding Machine with Twin Screw system is specially designed for producing HDPE and PP oil pots with clear liquid level lines. This Twin Screw Blow Molding Machine ensures stable material mixing and smooth extrusion, making oil containers stronger and more uniform in wall thickness.
Our Semi-Automatic Oil Pot Blow Molding Machine with Twin Screw system is specially designed for producing HDPE and PP oil pots with clear liquid level lines. This Twin Screw Blow Molding Machine ensures stable material mixing and smooth extrusion, making oil containers stronger and more uniform in wall thickness. The machine supports high-speed production while maintaining excellent bottle strength and surface quality. Ideal for cooking oil bottles, lubricant containers, and industrial oil packaging, this Oil Pot Blow Molding Machine offers flexible mold design, cost-effective operation, and reliable performance. The built-in liquid level line function improves product usability and market value for modern oil packaging production lines.
1.Liquid Level Line Design – Special mold structure allows oil pots to be produced with a clear liquid level line, improving product appearance and user convenience.
2.Twin Screw Stable Extrusion – Twin Screw Blow Molding Machine provides better plastic mixing and stronger bottle structure for HDPE and PP oil containers.
3.High-Speed Semi-Automatic Production – Combines efficient output with flexible manual operation, ideal for medium-scale Oil Pot Production Lines.
4.Improved Bottle Strength – Optimized blowing and cooling system produces durable, pressure-resistant oil bottles suitable for long-term storage and transportation.
5.Cost-Effective & Flexible Application – Supports various oil pot sizes and shapes with lower investment cost and quick mold change for different oil packaging requirements.
|
Model NO. |
YSD-PY5L |
Raw Material |
HDPE/PP/LDPE |
|
Making Method of Parison |
Extrusion-Blow Molding |
Automation |
Semi Automatic |
|
Computerized |
Computerized |
Certification |
CE, ISO9001:2008, Ysd |
|
After-sales Service |
24 Hours |
Machine Type |
High Speed Plastic Bottle Making Machine |
|
Control Mode |
PLC |
Motor Power |
11kw |
|
Total power |
17.5kw |
Blow Moulding Type |
Extrusion Blow Moulding |
|
Auto Deflashing |
Available |
Output(Dry Cycle) |
180PC/Hr; |
|
Die Head Option |
Single, Double, Tri-Head, Tetra-Head |
Production Usage |
Bottle, Toy, etc |
|
Max Container Capacity |
5L |
Transport Package |
Wooden Case |
|
Specification |
2800*1800*2000mm |
Trademark |
YSD |
|
Origin |
China |
Production Capacity |
500 |
|
Screwed diameter |
65mm/55mm |
|
Screwed diameter ratio |
1:25L/D |
|
HDPE Max Output |
40kg/h |
|
Material cutting method |
Hot knife |
|
Max mold size(L×W×H) |
220×300×380mm |
|
Blowing pressure |
0.4-0.6Mpa |
|
gas consumption |
0.5m3/min |
|
Power of mechanical and electrical extruder |
11KW |
|
Heating power of extruder |
10KW |
|
Total power |
23KW |
|
Dimension mm(L X W X H) |
2800*1800*2000mm |
|
Weight |
2.0T |
|
Control type |
PLC PC Control |
|
Suitable material |
PE/PP |
